aptly graph

aptly generates graph showing dependencies between mirrors, local repositories, snapshots and published repositories.

Command graph generates graph of dependencies:

  • between snapshots and mirrors (what mirror was used to create each snapshot)
  • between snapshots and local repos (what local repo was used to create snapshot)
  • between snapshots (pulling, merging, etc.)
  • between snapshots, local repos and published repositories (how snapshots were published).

Graph is rendered to PNG file using graphviz package.


$ aptly graph


  • -format="png": graph output format, could be anything graphviz supports, e.g. png, pdf, svg, …
  • -output="": specify output filename, default is to open result in viewer
  • -layout="horizontal": change between a horizontal and a vertical graph layout.


Example graph from aptly graph (horizontal)
